Hire Kramer Active Optical Armored 4K HDMI Cable - 100m

Designed specifically for use in staging, touring and installation environments, the Kramer CRS-PlugNView-H series offers a rugged and efficient solution for high-bandwidth video delivery. This 100 metre version supports resolutions up to 4K at 60Hz with full 4:4:4 colour fidelity, and carries data at up to 18 Gbps.

The cable features active optical technology which allows long-distance transmission without external power supplies, relying instead on the HDMI connector itself (approx. 0.25W). Its armoured construction includes Kevlar® reinforcement, a stainless steel corrugated tube, and a TPU jacket for enhanced durability in professional staging conditions.

Whether you select our full hire package—complete with delivery, flight-cased cable and technical support—or opt for dry hire to integrate into your own system, this cable delivers dependability, long reach and future-proof performance.

Key Features

• Supports 4K @ 60 Hz (4:4:4) over 100 m run
• Up to 18 Gbps data rate for high-bandwidth applications
• No external power required – draws power via HDMI interface
• Armoured construction: Kevlar® and stainless steel for rental/road use
• Supports full HDMI feature set: HDCP 2.2, HDR-10, HLG, Dolby Vision™, deep colour, x.v.Color™, Dolby TrueHD, DTS-HD
• Low Smoke Halogen Free (LSHF) jacket suitable for public venues

Specification

• Length: 100 metres (approx. 328 feet)
• Resolution Support: Up to 4K @ 60Hz (4:4:4)
• Data Rate: Up to 18 Gbps
• Connector Type: HDMI Type A male to HDMI Type A male
• Cable Construction: Optical fibre (50/125 µm OM3), Kevlar & stainless steel armour, TPU jacket
• Jacket Colour / Diameter: Black, approx. 5.8mm diameter
• Operating Temperature: 0 °C to 50 °C (storage –40 °C to +70 °C)

Applications

Ideal for rental and staging environments, corporate events, broadcast installations, live concerts and any scenario requiring long HDMI runs with professional reliability.

Hire Information

To hire this Kramer 100 m Active Optical Armoured HDMI Cable for your next production, please contact us for availability and pricing. Available as part of full AV system packages or on a dry hire basis.
