Hire Novastar CV10S

The CVT-10-S from NovaStar is a professional signal converter engineered for LED display systems requiring extended transmission distances and high bandwidth. With 2× 10 Gigabit optical (SFP) ports and 10× Gigabit RJ-45 Ethernet outputs, it supports conversion from fibre to Ethernet or vice-versa, facilitating both short and long-haul LED wall deployments. It is flash-ready for 8 or 16 Ethernet-port devices, and acts as a rack-mountable 1 U device suited for touring and fixed install rigs.

Whether you choose a fully supported hire package with technical setup and signal distribution, or opt for dry hire to integrate into your own system, the CVT-10-S offers a dependable backbone solution for LED wall signal infrastructure.

Key Features

• 2 × 10 G optical ports (single-mode) for long-distance signal runs up to ~10 km.
• 10 × 1 G Ethernet RJ-45 ports.
• Supports both Fibre-in → Ethernet-out and Ethernet-in → Fibre-out modes.
• Rack-mountable 1 U chassis, lightweight at approx. 2.1 kg.
• AC power input 100-240 V, 50/60 Hz; power consumption approx. 22 W.

Specification

• Model: CVT-10-S (single-mode fibre)
• Inputs/Outputs: 2× 10 G SFP ports; 10× Gigabit Ethernet RJ-45 ports.
• Dimensions (W × D × H): 254.3 × 290 × 50.6 mm approx.
• Weight: Approx. 2.1 kg net.
• Power Supply: AC 100–240 V, 50/60 Hz; ~22 W consumption.
• Operating Environment: −20 °C to +55 °C; humidity 10%–80% RH, non-condensing.

Applications

Ideal for LED wall systems at large events, touring productions, broadcast studios, corporate installations, or any scenario requiring high channel-counts and long cable runs where fibre-to-Ethernet conversion is needed.

Hire Information

To hire the NovaStar CVT-10-S for your next production, please contact us for availability and pricing. Available on dry hire if you will integrate it into your own LED wall system, or as part of a full LED system package including rigging, distribution and technical support.
