Hire Novastar MX40 Pro

Specifically designed for professional LED wall designers and rental companies, the MX40 Pro integrates advanced processing and connectivity in a single, compact chassis. It supports high-resolution inputs including HDMI 2.0, DP 1.2 and 12G-SDI with loop-through functionality. On the output side, the unit provides 20 × Gigabit Ethernet ports and 4 × 10G optical outputs, enabling control of up to 650,000 pixels @ 60 Hz (8-bit) or 325,000 pixels @ 60 Hz (10/12-bit) via compatible receiving cards.

Paired with NovaStar’s VMP (Vision Management Platform) software, it allows colour calibration, HDR workflow, 3D LUTs, advanced colour replacement and low latency performance. Whether you opt for a full hire package—complete with screen panels, rigging, signal distribution and technical support—or select dry hire for integration into your own system, the MX40 Pro delivers the capability needed for broadcast, touring, corporate, virtual-production and large-scale LED walls.

Key Features

• 3 × HDMI 2.0 inputs (up to 4096×2160 @ 60 Hz)
• 1 × DP 1.2 input (4096×2160 @ 60 Hz)
• 1 × 12G-SDI input (supports 4096×2160, ST-2082 etc.)
• 20 × Ethernet output ports + 4 × 10G optical outputs
• Supports 3D, HDR10, dynamic colour correction and calibration tools
• Low latency design and integrated network switch for cascading multiple devices
• Power input 100-240 V AC, consumption approx. 70 W; Dimensions 482.6 × 467.0 × 94.2 mm; Weight 7.5 kg

Specification

• Model: MX40 Pro
• Inputs: HDMI 2.0 (×3), DP 1.2 (×1), 12G-SDI (×1)
• Outputs: 20 × Gigabit Ethernet ports; 4 × 10G optical SFP ports
• Max Output Pixels: Up to ~650,000 pixels @60 Hz (8-bit)
• Power Supply: AC 100-240 V, 50/60 Hz
• Power Consumption: Approx. 70 W
• Dimensions (W × D × H): 482.6 × 467.0 × 94.2 mm
• Weight: 7.5 kg
• Compatibility: Works with NovaStar VMP software and a range of receiving cards.

Applications

Ideal for live events, touring productions, broadcast studios, corporate AV installations, virtual production and large-scale LED wall projects where high quality, signal flexibility and large pixel counts are essential.

Hire Information

To hire the NovaStar MX40 Pro LED Display Controller for your next event or installation, please contact us for availability and pricing. Available as part of full LED wall packages or for dry hire within your own system.
